Hikmicro BX20 Intrinsically Safe Thermal Camera HM-TP52N-3AQF-BX20

Hikmicro BX20 Intrinsically Safe Thermal Camera HM-TP52N-3AQF-BX20

Product Code: HIKBX20

Price
£1379.00 ex. VAT £1654.80 inc. VAT

In Stock


Add To Favourites
Detailed Description

ATEX & IECEx Certified Compact Intrinsically Safe Thermal Camera for Hazardous Areas

HIKMICRO BX20 is certified to measure temperature in many explosive environments to quickly find invisible faults. It’s equipped with a 256 × 192 resolution thermal detector and a 2 MP visual camera. The temperature ranges from -20°C to 550°C (-4°F to 1022°F), which meets the most situation. It helps the staff to quickly find the fault according to accurate temperature measurements of high-temperature targets in the environment. Meanwhile, it provides assistance in the decision and ensures safety.

*Important Calibration Information:

This instrument comes complete with the manufacturer’s calibration certificate. Please be aware that these certificates are generic and may also be time-lapsed. If you would prefer a personalised full traceable calibration certificate applied to the equipment before dispatch, then please select this option from the drop-down menu above, an additional calibration charge will apply.

Hikmicro BX20 Comes Supplied With:

  • Thermal Camera with Wrist Strap
  • USB 2.0 A to USB Type-C Cable
  • Power Supply
  • International Use Plugs (US/EU/UK/AU/CN)
  • Calibration Certificate
  • Quick Start Guide


A digital thermal camera with a USB cable and charger, ideal for capturing heat signatures

Key Features:

  • ATEX: II 3 G Ex ic IIC T6 Gc, II 3 D Ex ic IIIC T85°C Dc
  • IECEx: Ex ic IIC T6 Gc, Ex ic IIIC T85°C Dc
  • Thermal resolution: 256 × 192 (49,152 pixels)
  • Temperature measurement range : -20°C to 550°C (-4°F to 1022°F）
  • 25 Hz image frequency
  • 3.2'' LCD screen display
  • Up to 6 hours of continuous running

Certified Product and Manufacturer

Not only the HIKMICRO BX20 intrinsically safe thermal camera has obtained ATEX and IECEx certification. In addition, HIKMICRO is an audited manufacturer of hazardous location equipment and gets ATEX Quality Assurance Notification (QAN) and IECEx Quality Assurance Report (QAR).

High Image Quality

Features a high Resolution (256 × 192, 49,152 pixels) and highly sensitive (NETD < 40 mK) VOx IR detector, along with HIKMICRO SuperIR image enhancement algorithms to provide super clear thermal images.

Enhanced Thermal Clarity with SuperIR

Powered by HIKMICRO SuperIR image enhancement technology, it upscales the resolution of captured thermal images to 320 x 240 (76,800 Pixels). (*SuperIR enables captured thermal images only)

Infrared thermal imaging camera displaying Super IR technology detecting heat signatures, with a before-and-after comparison of the device being turned on

25 Hz Fast Image Frequency

25 Hz fast image frequency delivers smooth video while panning across scenes or viewing moving targets.

Full-screen Precise and Wide Measurement

Supports capture of full-screen radiometric images and automatically tracks max/min/center spots to pinpoint temperature anomalies at a glance. Accurately measures temperatures from -20°C to 550°C with a temperature accuracy up to +/-2°C or +/-2% of reading.

Durable and Rechargeable Batteries

Built-in 3350mAh Li-Ion rechargeable battery and thoughtful auto power-off settings (10/20/30/40/50/60 minutes) allow the camera up to 6 hours of continuous operation.


Dual-camera Thermal Imager

Built-in IR camera and visual camera give you enhanced details. Thermal, Fusion, PIP, and Visual modes to suit your preferred view.

HIKMICRO Viewer App

Conveniently share images and reports, connect the HIKMICRO Viewer App via Wi-Fi to transfer photos or videos from the camera to a mobile device. Analyze, share images, and generate reports in real-time on-site.

play-store    App-store

Hikmicro BX20 Technical Specification
Infrared Image
IR Resolution 256 × 192 (49,152 pixels)
NETD < 40 mK (@ 25 °C, F#=1.0)
Image Frequency 25 Hz
Detector Pitch 12 μm
Spectral Range 7.5 to 14 μm
Focal Length 3.6 mm
F-number F1.0
Field of View (FOV) 37.2° × 50.0°
Spatial Resolution (IFOV) 3.3 mrad
Min. Focus Distance 0.3 m (0.98 ft)
Focus Mode Focus Free
Image Display
Visual Camera 1600 × 1200 (2 MP)
Display 240 × 320 Resolution, 3.2” LCD Screen
Color Palettes White Hot, Black Hot, Rainbow, Ironbow
Color Alarm Above alarm
Image Modes Thermal/Visual/Fusion/PIP
Measurement and Analysis
Object Temperature Range -20°C to 550°C (-4°F to 1022°F)
Accuracy Max. (± 2°C/3.6°F, ± 2%), for ambient temperature 15°C to 35°C (59°F to 95°F) and
object temperature above 0°C (32°F)
Measurement Tools Center Spot, Hot Spot, Cold Spot
User-definable: 3 spots
Level and Span Mode Auto/Manual
Data Storage and Communication
Storage Media Built-in 16 GB flash memory
Image Storage Capacity Approx. 90,000 Images
General
LED Light Yes
Battery Type Rechargeable Li-ion battery
USB Interface USB Type-C
Battery Operating Time Approx. 6 hours
ATEX / IECEx Certificate Type ATEX: II 3 G Ex ic IIC T6 Gc, II 3 D Ex ic IIIC T85°C Dc
IECEx: Ex ic IIC T6 Gc, Ex ic IIIC T85°C Dc
Battery Charging Time Approx. 3 hours fully charged
Protection Level IP54
Drop Test Height 2 m (6.56 ft)
Working Temperature Range -20°C to 50°C (-4°F to 122°F)
Storage Temperature Range -20°C to 60°C (-4°F to 140°F)
Relative Humidity < 95% non-condensing
Weight Approx. 380 g (0.84 lb)
Dimension 221.7 × 73.5 × 123.8mm (8.73 × 2.89 × 4.87 in)
Tripod Mounting UNC ¼”-20
